Model Name
QBX
Case Form Factor Mini-ITX Case
Motherboard Type Mini-ITX
Dimension (WxHxD) 7.01 x 11.46 x 15.12 (in)
178 x 291 x 384 (mm)
Optical Disk Drive (ODD) Type Supports ONLY Slot Loading Slim ODD
3.5" Internal Drive Bay (HDD) 1
2.5" Drive Bay (HDD/SSD) 4
Expansion Slots
(For example for Graphics Cards) 2
I/O Panel 2 x USB3.0/HD audio
Cooling System Max. Supported Installation:
Seven Fans Front 80mm fan x 1 (optional)
Top 120mm fans x 2 (optional)
Rear 90mm fan x 1 (pre-installed)
Bottom 120mm fans x 2 (optional)
Left Side 120mm fan x 1
or
240mm radiator with a single 120mm fan
or
120mm radiator with a 120mm fan
Cable Management System Cable feedthrough on the motherboard tray for easy routing and hiding of cables.
Fan Filter (Cleanable) 1 x Bottom Filter (pre-installed and removable)
1 x Front Filter (included, installed by the user)
Water Cooling Support Left Side:240mm radiator with a single 120mm fan
or
Left Side:120mm radiator with a 120mm fan
Max. Graphics Card Length 350mm (Support for High-End Graphics Cards)
(Horizontal graphics card slots are compatible
with RTX 3080/3070.)
Max. CPU Cooler Height 105mm
PSU PS2 ATX Type
Max. PSU Length 140 mm / 5.5 (in)
Compatible PSU supports the following COUGAR PSU series:
A Series and STX Series.
