DISPLAY
Monitor Size: 27”W (27” Viewable)
Panel Technology: IPS TFT LCD
Resolution: WQHD 2560 x 1440
Display Area: 596.74mm (H) x 335.66mm (V)
Aspect Ratio: 16:9
Brightness: 300 cd/m² (Typ)
Contrast Ratio: 1000:1 (Typ)
Dynamic Contrast Ratio: 50,000,000:1
Viewing Angle: 178 degrees / 178 degrees (Typ)
Response Time: GTG: 5ms (Typ)
Colours: 1.07 Billion colors (10 bits)
Colour Gamut: Adobe RGB: 79.15% Panel Coverage
NTSC: 71.66% Panel Coverage
sRGB: 99% Panel Coverage
REC 709: 99% Panel Coverage
SMPTE C: 100% Panel Coverage
EBU: 99% Panel Coverage
Pixel Pitch: 0.2331mm (H) x 0.2331mm (V)
INPUT SIGNAL
Frequency: Fh = 15 ~ 120KHz ; Fv = 24 ~ 75Hz
Sync: TMDS / PCI-E
COMPATIBILITY
PC: Windows 10 certified
Mac®: Power Mac tested
CONNECTOR
Digital: HDMI 1.3 x 2
DisplayPort 1.2 x 1
Audio Out: Earphone out x 1 (3.5mm plug)
Audio In: Audio in x1 (3.5mm plug)
SPEAKERS
3W x 2
POWER
Power: 3-pin plug (CEE22) x 1
Voltage: AC 100-240V (Universal); 50/60Hz
Consumption: 33W
Optimize: 27W
Conserve: 21W
ERGONOMICS
Tilt: 22 ~ -5 degrees
Swivel: 320°
Rotation: 90°
Height Adjustment: 110 mm
WALL MOUNT
VESA®: 100mm x 100mm
OPERATING CONDITIONS
Temperature (º F / º C): 32°F to 104°F (0°C to 40°C)
Humidity: 20% to 90% (no condensation)
DIMENSIONS (W x H x D) (mm)
Physical with stand (mm): 620 mm (W) x 534 mm (H) x 245 mm (D)
Physical without stand (mm): 620 mm (W) x 362 mm (H) x 44 mm (D)
Packaging (mm): 190 mm (W) x 444 mm (H) x 725 mm (D)
WEIGHT
Net with stand (kg): 6.91kg
Net without stand (kg): 5.96kg
Gross (kg): 8.6kg
REGULATIONS
CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, GS, UKCA, BSMI, VCCI, PSE, KC/KCC, e-Standby, CCC, China RoHS, China Energy Label
PACKAGE CONTENTS
LCD Display
Power Cable (1.5m)
HDMI Cable (1.5m)
Audio Cable (1.5m)
Quick Start Guide
*Actual content may differ from market to market
